How to Install H7 LED Headlight Bulb

Views: 0     Author: Site Editor     Publish Time: 2022-05-20      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


1.Take out cover,anti-Clockwise rotate to take out halogen bulb, take off the halogen from the original holder and Separate LED headlight bulb’s ring

Take off the halogen from the original holder



Separate LED headlight bulb’s ring


2.Holder for VW/BENZ/BMW

Install the ring and the correct case holder together

Holder for VW、BENZ、BMW



3.Holder for HYUNDAI/KIA

Holder for HYUNDAI、KIA


4.Clockwise rotate(only) to adjust the light bulb direction.LED chips face to 3 o’clock and 9 o’clock direction.Adjust the light bulb direction


5.Install the CANbus if you have a flickering,error warming issue.Connect the plug with the CANbus,the white side is postive,the black side is negative.Finally,cover the cover.

Connect the plug with the CANbus
